Description
Warning! This item is not suitable for flammable liquids
Specifications
- Air Ratio: 1:1
- Fluid Inlet/Outlet: 2″ NPT
- Max Flow: 155 GPM
- Air Inlet Port: 1/2″ NPT
- Body Construction: Aluminum
- Diaphragms: Buna N
- Balls: Buna N
- Seats: Buna N
- UL Listed: No
- Air Consumption: 100CFM @ 100PSI
- Bolt Pattern: 10.00″ X 9.00″
- Height: 26.500″
- Max Particle Size: 1/4″
- Suction Lift- Dry: 20″
- Suction Lift- Wet: 25″
