Standard Indicator, Lug Back, ISO Type, 10mm, 0,01mm 2046S-15 Low Force 0.4-1.4N

Original price was: $32.00.Current price is: $25.60.

SKU: 2046S-15 Category:

Description

Standard Type, 10 mm Range, 0,01 mm Graduation

This is a standard dial indicator. It offers you the following benefits:

  • Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
  • No through screw holes on the frame as well as the use of an O-ring prevents water or oil penetration.

Features

Digital/Analog: Analog

Inch-Metric: Metric

Functions: ISO type

Delivered: With certificate of inspection

Range: 10 mm

Range
per rev.:
1 mm

Dial reading: 0-100

Graduation: 0.01 mm

Measuring force: 0,4 – 1,4 N

MPE any 1/10
revolution:
5 m

MPE any 1/2
revolution:
9 m

MPE any 1
revolution:
10 m

MPE measuring range: 13 m

H MPE
(Hysteresis):
3 m

R MPE
(Repeatability):
3 m

Mass: 144 g

Stem: 8 mm

Contact point: Carbide tipped, thread: M 2.5 x 0.45 mm

Continuous dial: Yes
