Description
Technical Datasheet
*OTHER PRESSURE RANGES AVAILABLE ON REQUEST*
The PDK PDR1000 Digital Pressure Gauge offers the best performance in its class and is produced with PDK’s unique pressure calibration technology. The PDR1000 offers 0.025% Full-Scale Accuracy, simple button touch operation for various functions, an analogue output option and a built-in data logging function. The PDR1000 is the perfect solution for systems that require near-perfect pressure performance.
Contact the GTS Team to learn more about the PDK PDR1000 and our brand new range of PDK Digital Pressure Gauges today.
Features:
- 110mm Dial
- Bottom-Entry Thread Connection
- Ultra-High 0.025% Full-Scale Accuracy
- Analogue Output Option Available
- Built-in Datalogging Function
- Simple Button Touch Operation
- Full selection of pressure units to display:
- mbar, bar , MPa, mmH20, inHg, mmHg, kgf/cm2, atm, psi, kPa
- Auto-Off Function
- Backlit LCD Display
- Min/Max Function
- Calibration Function
- Silicone Cover Included
FAQ:
Where do I download the PC app for PDR500 and PDR1000 PC datalogging?
Click Here!
Is the Bluetooth datalogging APP available for Apple devices?
No, currently it is only available for Android devices.
How do I download the Bluetooth datalogging APP for my android?
Click this Link or you will need to search PDR 500 on the Google Play Store ensure there is a space after PDR and before 500
My PC is not recognizing my digital pressure gauge?
If you have a Bluetooth enabled device you need to turn Bluetooth OFF in order for the cable datalogging to PC to successfully communicate. This is done by:
1 – Turn OFF the PDR500 device
2 Press Unit and Power button at the same time for 2 seconds, then release buttons.
3 Bluetooth logo should disappear on start up, activating the datalogging communication to PC
4 Note Bluetooth will automatically turn back on every time the device is power cycled.
Programmers Reference Guide
