P1776 100mm Bottom-Entry Pressure Gauge: Brass Internals, 3/8 BSPT

Description

FREE SHIPPING ON ORDERS OVER $40!

Buy Pressure Gauge Adaptors, Shrouds and More Here!

Data Sheet P1776 & P1777

Pair this Bottom-Entry Pressure Gauge with aRUBBER SHROUD. Protect your gauge from bumps and knocks to ensure durability and longlasting accuracy!

The Heavy Duty pressure gauges with glycerine filling are used at measuring points with high dynamic alternating loads and strong vibrations and pulses. The glycerine filling ensures smooth pointer movement and thus good readability even in extreme load and strong vibration conditions.

The lubricating effect of the glycerine also provides protection against increased wear. The modern modular construction system with an o-ring sealing system, tried and tested for many years, ensures a high level of functional safety and a long service life.

Case components are composed of stainless steel.

Specifications:

• Test of mergin an excel spreadsheet 100mm diameter
• High reliability and long service life due to modular construction system
• Overload capacity 1.3x
• Protection to IP 65
• Accuracy class 1.0
• Case Materialstainless steel
• Wetted Parts brass
