Moore & Wright Metric Steel Gauge Blocks 700 Series

Description

Features

• Made from high quality stress relieved alloy steel
• Hardened to HV820 (HRC65)
• Excellent rigidity
• Size and serial number are engraved on each individual gauge block
• Available in 2 grades – Grade 1 for Inspection, Grade 2 for Workshop
• All sets have a MOORE & WRIGHT certificate

Code No.

Description

No. of Blocks

MW700-02

Grade 1

103

MW700-03

Grade 2

103

MW700-05

Grade 1

87

MW700-06

Grade 2

87

MW700-08

Grade 1

47

MW700-09

Grade 2

47

MW700-11

Grade 1

32

MW700-12

Grade 2

32

No. blocks Nominal size Qty Step (mm) No. blocks Nominal size Qty Step (mm) No. blocks Nominal size Qty Step (mm) No. blocks Nominal size Qty Step (mm) 103 1.005 1 47 1.005 1 87 1.001-1.009 9 0.001 32 1.005 1 1.01-1.49 49 0.01 1.01-1.09 9 0.01 1.01-1.49 49 0.01 1.01-1.09 9 0.01 0.50-24.50 49 0.5 1.10-1.90 9 0.1 0.50-9.50 19 0.5 1.10-1.90 9 0.1 25.0-100.0 4 25 1.0-24.0 24 1 10.0-100.0 10 10 1.0-9.0 9 1 25.0-100.0 4 25 10.0-30.0 3 10 60.0 1
