Description
Features
Standard: DIN 863
Digital functions: mm / inch conversion, set, on/off, zero-setting, battery low indication, hold, 0…ABS
Interchangeable rods (spherical ends)
Rods are hardened and spherically lapped
Satin chrome finished base
Constant force ratchet on thimble
Code No.
Range (mm)
Range (inch)
Accuracy (mm)
Resolution (mm)
Resolution (inch)
Size of Base (mm)
MW305-00DDL
0-25
0-1
0.004
0.001
0.00005
100
MW305-01DDL
0-50
0-2
0.004
0.001
0.00005
100
MW305-02DDL
0-100
0-4
0.005
0.001
0.00005
100
MW305-03DDL
0-150
0-6
0.006
0.001
0.00005
100
MW305-04DDL
0-200
0-8
0.007
0.001
0.00005
100
MW305-05DDL
0-300
0-12
0.009
0.001
0.00005
100
