| Wireless communication protocol: |
Proprietary (2,4 GHz by original specification based on IEEE 802.15.4)
|
| Modulation method: |
DS-SS (Direct Sequence Spread Spectrum)
|
| Measuring Instruments: |
COOLANT PROOF (IP65)
micrometer, indicator
|
| Remarks: |
Standard
|
Data reception
indication: |
Buzzer and LED
(green, red, orange)
|
| Communication distance: |
Approx. 20 m (within visible range)
|
| Communication speed kbps: |
250
|
| Power supply: |
Battery CR2032 x 1 pcs.
|
| Communication with measuring tool: |
Digimatic (6 digits), Digimatic 2 (8 digits) automatic identification
|
| Communication frequency: |
2,4 GHz band (2,405-2,475 GHz, 15 channels, 5 MHz interval)
|
| Transmission output: |
2,5 mW (4 dBm) or below
|
| OS compatibility: |
Windows 2000 Professional (SP4),
Windows XP Professional (SP2), Windows XP Home Edition (SP2), Windows Vista, Windows 7 (32bit, 64bit), Windows 8, 8. 1, 10 (32bit, 64bit), 11
|
| Battery life: |
Approx. 400000 transmissions
|
| Delivered: |
Including screwdriver, CR 2032 battery, key for battery case
|
