Description
Imperial Analogue Outside Micrometer – Ratchet Stop
Series 103
A Mitutoyo basic, cost effective, non-digital micrometer with a ratchet stop to guarantee repeatable measurement.
Specifications
- Digital/Analog: Analog
- Inch-Metric: Inch
- Graduation: 0,001″
- Maximum Permissible Error J MPE: 0.001″
- Flatness: 0.000024″
- Parallelism: 0.00008″
- Measuring spindle: With spindle lock, 6,35 mm (300 mm) 8 mm (>300 mm) , spindle pitch 0,5 mm
- Scale: Thimble and sleeve satin chrome finish, 18 mm
- Measuring force: 5-10 N (from 100 mm upward : 5-15 N)
- Delivered: Including box, setting standard (from 1″ upward), key, certificate of inspection (0-2″ range)
- Mass: 175 g
All images are for representation only.
