Mitutoyo Digital Disc Micrometer IP65 Inch/Metric, 0-1, Disk=20mm 323-350-30

Description

• This Digimatic Disc Micrometer enables you to measure hard-to-reach features,
  offering you the following benefits:

  • Measuring the root tangent length of spur and helical gears.
  • You can measure recessed features that are difficult to reach with a standard micrometer.

  Specification

  Digital/Analog: Digital

  Delivered: Including box, spanner, 1 SR44 battery

  Inch-Metric: Inch/Metric

  Range: 0 – 1 “0-25mm

  Digital step: 0,00005″/0,001 mm

  Max.
  Permissible Error
  J MPE: 0,0002″/.005mm Parallelism: 0,00016″/.004mm

  Display: LCD, character height 7.5 mm

  Measuring face: Hardened steel, micro-lap finish

  Measuring spindle: With spindle lock, 6,35 mm, spindle pitch 0,5 mm

  Scale: Thimble and sleeve satin chrome finish, 18 mm

  Measuring force: 3 – 8 N

  Power supply: 1 battery SR-44
