Description
Indicator Features:
- Range: 0-0.8mm
- Resolution: 0.01mm
- Accuracy: 0.008mm
- MPE any 10 scale divisions: 0.005mm
- MPE Measuring range: 0.008mm
- Hysteresis: 0.003mm
- Repeatability: 0.003mm
- Scale: 0-40-0
- Measuring Force: 0.3N or less
- 8mm stem
- Contact point thread: 1.75 x 0.35mm
- MPN:513-454-10E
This is a Dial Test Indicator (Lever Type) which offers you the following benefits:
- Drastically enhanced durability, sensitivity and visibility.
- Glare-free flat crystal face allows easy reading of graduations.
- O-ring seal on the bezel has the effect of providing smooth rotation and prevents dust and oil from penetrating through to the dial face.
- The stylus length is on the dial face to reorder a replacement
- Multi-layer coatings on the crystal
Basic Set includes:
- Knurled clamp ring
- 8mm stem diameter
- Stylus 2mm diameter carbide contact point
