Description
Shore D Durometer LX-D Rubber Plastic Hardness Tester 0-100HD ASTM D2240 NEW
Introduction:
Designed for testing the hardness of various hard plastic, rubber, glass, printed board, fiber, colophony, such as thermo plastics, flooring and bowling balls.
1.Tippered Pin 30
2.Full 360 deg sweep
3.Simple structure
4.Easy operation
5.Large dial, easy reading
6.Complied with ASTM D2240, ISO/R686, DIN 53505, and JIS R7215
7.Can be adapted with optional hardness test stand
Parameter:
1.Measuring range: 0 – 100 Shore D units
2.Measuring spring force: 4.45-44.5 N
3.Depth of indentation: 0 – 2.5 mm ( the testing material has to be thicker than 6 mm)
4.Test pressure: 50 N
5.Dial diameter: 55 mm
6.Dimensions: 115 x 60 x 25 mm
7.Weight: 200 g (net); 300 g (gross)
