The MEGR-164 Series adjustable high-pressure regulators off er a wide selection of available pressure ranges. High pressure regulators are typically used to reduce tank pressure to an intermediate pressure for use by another regulator. They may be used as high pressure regulators on distribution on systems when used in conjunction on with first-stage down stream regulators.
When equipped with an integral relief valve (MEGR-164SR Series), the regulator may be used as a final-stage regulator on high pressure systems. It may also be used as a first-stage regulator when set at 10 PSIG (0,69 bar) or less. The 1/4-inch FNPT tapped side outlet can be used to install a pressure gauge or a hydrostatic relief valve. This series contains brass materials that are not compatible with anhydrous ammonia service.
Features / Specifications:
- Type: Adjustable/PSI
- Max. Inlet Pressure: 250 PSI
- Inlet and Outlet Connection: 1/2 FNPT, 3/4 FNPT or 1″ FNPT
- Optional Internal Relief Valve (Only Available with 1/2″ Connection)
- Exterior Finish: Gray Urethane
- Regulator Spring: Steel
- Stem Guide/Disk Holder: Stainless Steel
- Diaphragm: Fabric Rienforced Nitrile (NBR)
- Bonnet / Body Material: Cast Aluminum
- Vent: Non-Relieving
Options:
Resources:
- Marshall Excelsior 164 Regulator Instruction Manual
- Marshall Excelsior 164 RegulatorManual de Instrucciones (Espaol)
- Marshall Excelsior 164 Regulator Bulletin
