Description
MarTest 800S Lever-Type DTI 4305200
Specification
- Measuring range mm 0.4
- Product type 800 S
- Graduation value mm 0.01
- Standard DIN 2270
- Figure on dial face 40-0-40
- Range per rev. in mm 0.8 mm
- Span of error fe (m) 10 m
- Total span of error fges (m) 13 m
- Measuring value hysteresis fu (m) 3 m
- Partial measuring range ft (m) 5 m
- Repeatability fw (m) 3 m
- Measuring force 0.15 N
- Scale diameter 27.5 mm
All images are for representation only.
