Mahr MarCal 16 EWR IP67 Digital Caliper 0-150mm, 0-200mm (Rectangular Depth Rod)

Description

• High contrast digit display
• Locking screw above
• Lapped guideway
• Measuring blade for inside measurements
• Slide and beam made of hardened stainless steel
• Step measuring function
• Immediate measurements due to the Reference System
• Raised guideway for the protection of the scale
• Excellent resistance against dust, coolants and lubricants
• Dirt wipers are integrated in the slide

0-150mm/6″:

Measuring range mm 0 – 150 Measuring range inch 0 – 6″ Resolution mm/inch 0.01 / .0005″ Standard DIN 862 Error limit (mm) 0.03mm Error limit inches .001″ Depth Rod rectangular Battery type CR 2032 (3V Lithium) Dimensions a 10 mm | b 40 mm | c 16 mm | d 235 mm | e 16 mm |

Please select caliper size.

0-200mm/8″:

Measuring range mm 0 – 200 Measuring range inch 0 – 8″ Resolution mm/inch 0.01 / .0005″ Standard DIN 862 Error limit (mm) 0.03mm Depth Rod rectangular Error limit inches .001″ Battery type CR 2032 (3V Lithium) Dimensions a 10 mm | b 50 mm | c 19 mm | d 285 mm | e 16 mm |
