Description
Functions:
ON/OFF
RESET (Set display to zero)
mm/inch
Reversal of the counting
direction
PRESET (Allows the entry of any value using set buttons)
TOL (Enter tolerance limit values)
ABS (Display can be set to zero, without losing the reference to the Preset value)
<0> (Tolerance GO / NO GO display mode)
DATA (when connected with a data connection cable)
Factor (adjustable)
Immediate measurement due to the Reference system
Individual buttons can be locked – Lock Function
Operating and display unit (bezel) can be rotated 280
High contrast LCD with 11 mm high digits
Inductive measuring system, battery life ca. 2000 hrs.
Maximum measuring speed 1.5 m/s(60/s)
Lifter protection cap on the measuring spindle
MarConnect data output: choose either USB OPTO RS232C Digimatic
Operating temperature 10 – 40C
Class of protection IP42 in accordance to IEC 60529 Supplied with: Battery, operating instructions
Mahr 4337171 Digital Indicators MarCator 1087 R
