Description
Features:
-
Analogue scale
-
Adjustment rods
-
IP65 Sealed
-
Water, coolant, oil and dust resistant
-
Ratchet drive
-
Locking screw
-
Zero at any point
-
mm-inch conversion
-
Carbide measuring faces
-
Hardened stainless steel spindle
-
Incremental or absolute measurements
-
Measuring force: 5-10N
-
Power: 1.5V LR44 Battery (Included)
Range
Resolution
Accuracy
Setting standard
0-100mm (0-4)
0.001mm (0.00005)
0.005mm (0.00025)
25mm, 50mm, 75mm
100-200mm (4-8)
0.001mm (0.00005)
0.006mm (0.0003)
100mm, 125mm, 150mm, 175mm
200-300mm (8-12)
0.001mm (0.00005)
0.007mm (0.00035)
200mm, 225mm, 250mm, 275mm
300-400mm (12-16)
0.001mm (0.00005)
0.008mm (0.0004)
300mm, 325mm, 350mm, 375mm
400-500mm (16-20)
0.001mm (0.00005)
0.009mm (0.0004)
400mm, 425mm, 450mm, 475mm
