Description
FREE EXPRESS AIRBAG SHIPPING ON ORDERS OVER $40!
Technical Datasheet
Adaptors to Suit
A welcome addition to our product line, the GTS Temperature Switches are perfect for many different applications and industries. Featuring available Fixed Switch Points from 38C125C and a Two-Terminal, Above-Earth Connection with Spade Terminals, the GTS Temperature Switches are reliable, accurate and trustworthy. Constructed from high-quality brass material, the GTS Temperature Switch comespre-set to either the N/O or N/C switch position. The 1/8NPT thread is adaptable with modifying adapters also available from GTS with all our Temperature Switches also coming equipped with an additional rubber boot for protection.
Features:
- Brass Housing Material
- Fixed Switch Points Available From: 38C125C
- Two-Terminal Above-Earth Connection
- Easily Adaptable 1/8″NPT Thread
- Rubber Boot Protection Included
- Silver Plated Electrical Contacts
- Electrical Rating: 240V AC – 5A (resist) + 24V DC – 6A (resist)
- Hysteresis: 5C
- IP54 Protection
- Environmental: -20C to +120C
- 20mm Probe with Spade Terminal
- Setting Tolerance: +/-5C
- Varying Male thread size Adaptors to suit
