Description
Tesa GT22 Standard Axial Inductive Probe
PROBE
– Measuring bolt mounted on a ball bearing
– Separate guiding from the housing so that the movement of the measuring bolt moves easily even if the probe is not clamped appropriately
– Guiding is insensitive to any radial force exerted on the measuring bolt
– 8 mm probe housing, can be clamped over its entire length
– The guides are effectively protected against penetration of liquids (oils) or solids (dust) by sealing bellows
– Version with detachable cable available (depending on model)
MEASUREMENT
– Axial movement
– The measuring force can be adjusted by changing the spring (depending on model)
– The measuring inserts can be replaced or exchanged
All images are for representation only.
