Data Sheet GLL43
The mechanical level gauges GLL43 Series
They are mounted vertically from the top of the tank so as the liquid level changes, the float follows that change and uses a magnetic coupling to transfer that motion from the float to the level indicator dial.
The gaugesare completely sealed so there is no risk of the tank contents leaking through the gauges header.
The gauges can also be fitted with an electrical interfacing dial indicator, as well as indicators with set switching points.
Fluid Types:
- Fluids compatible with the construction materials.
GLL43 Construction:
- Header: Zinc alloy
- Guide rails and foot bar: 316 stainless steel
- Spiral drive: Brass
- Float: Polypropylene
- Dial capsule: Polycarbonate
