Digital Thickness Gauge, High Accuracy Inch/Metric, 0-0,47, 0,00005 547-400A
Product image
-71%
Product image
Product image

Digital Thickness Gauge, High Accuracy Inch/Metric, 0-0,47, 0,00005 547-400A

Original price was: $511.70.Current price is: $148.00.

SKU: TEEKddtO2PvJO Category:

Description

Mitutoyo; Digital Thickness Gauge

escriptionThis ABSOLUTE Digimatic Thickness Gauge with 1 m digital step enables you to measure film, paper, etc., with flat contact points.

  • Bidirectional communication e.g. to perform parameter setting from a PC (Digimatic S 1 interface) is possible.

Specification

Digital/Analog: Digital

Inch-Metric: Inch/Metric

Functions: With Indicator ID-C No.543.0-701.0BS

Delivered: In a box with CR2023 battery, battery lid opener, spindle lifting lever 21AZB149

Range: 0 – 0,47 “

Type: D= 6.3 mm carbide tipped

Digital step: 0,00002″/0,0005 mm

Accuracy: 3 m

Parallelism: 0,0001″/ 0,003 mm

Protection: IP42

Indicator No.: 543-701-10BS

Max. measuring depth: 21 mm

Measuring force: 3,5 N

Display: LCD, character height 11 mm

Alarm: Low voltage, setting errors, sensor error, display overflow a.s.o.

Power supply: 1 battery CR2032 (3V)

Battery life: Continuous use: approx. 2700h

DATA/HOLD: Yes

Digimatic data output: Yes

ON/OFF: Yes

Function lock: Yes

GO/NG judgement: Yes

ABS / INC (INC ZERO): Yes

Calculation function (with formula): Yes

Counting direction switchable: Yes

Digimatic S1 Bidirectional interface: Yes

Analog bar resolution selection: Yes

Auto Power OFF setting: Yes

Analog bar resolution switchable: Yes

Customizing keys: Yes

Inch/Metric switchable: Yes

Calibration warning function: Yes

Digital step switchable: No

Digital Scale: Electrostatic capacitance type absolute linear encoder

Mass: 275 g
