Digital Thickness Gauge, Flat Type Inch/Metric, 0-0,4, 0,0005 547-300S
Product image
-55%
Product image
Product image

Digital Thickness Gauge, Flat Type Inch/Metric, 0-0,4, 0,0005 547-300S

Original price was: $324.10.Current price is: $145.00.

SKU: 547-300S Category:

Description

A Mitutoyo digital-indicator based instrument designed for quick and efficient measurement of small dimensions. Ideally suited for measuring the thickness of paper, film, wire, sheet metal and similar materials. The convenient grip handle, thumb trigger and spring-loaded plunger make the instrument easy to use.

Specification

Inch-Metric: Inch/Metric

Functions: With indicator ID-C No. 543-402BS (ANSI/AGD type)

Digital step: 0,0005″/0,01 mm

Accuracy: 20 m

Parallelism: 0,0005″

Indicator No.: 543-400BS (ID-C)

Max. measuring depth: 30 mm

Measuring force: 1.5 N

Alarm: Low voltage, counting value composition error, overflow error, tolerance limit setting error (ID-C only)

Contact point: Thread # 4-48UNF

Power supply: 1 battery SR-44

Battery life: approx. 7000 hours

DATA/HOLD: Yes

Digimatic data output: Yes

ON/OFF: Yes

Function lock: Yes

GO/NG judgement: Yes

ABS / INC (INC ZERO): Yes

Calculation function (with formula): Yes

Counting direction switchable: Yes

Digimatic S1 Bidirectional interface: Yes

Analog bar resolution selection: Yes

Auto Power OFF setting: Yes

Analog bar resolution switchable: Yes

Customizing keys: Yes

Inch/Metric switchable: Yes

Calibration warning function: Yes

Digital step switchable: Yes

Mass: 255 g
