Digital Micrometer QuantuMike IP65 Metric, 25-50mm, with Bidirectional Output Item number: 293-141-40

Description

PDF

This is an IP65 micrometer offering movement four times as fast as a standard micrometer.

It presents you with the following benefits:

• Faster measurement is achieved by using a coarser thread which feeds the spindle by 2 mm per thimble rotation.
• Bidirectional communication e.g. to perform parameter setting from a PC (Digimatic S 1 interface) is possible.
• Ratched thimble mechanism and a small design ensures easy single-handed or stand operation.
• Equipped with a calibration schedule warning function.
• GO/NG judgement is performed by setting the upper and lower tolerance limits.
• Approach speed warning function for reliable measurements.
• Extraordinary battery life of 2 years (4000 h).
• Outstanding accuracy refer to EN ISO 3611 J_MPE1 m (0-25, 25-50 mm model).
• Excellent resistance against water and dust (IP65 protection level) enables this micrometer to be used in machining situations that include splashing coolant fluid.
• A function lock protects the display against unauthorized use.
• Visibility is improved by enlarging the display unit.

Digital/Analog: Digital

Delivered: Including box, spanner, CR2032 battery, certificate of inspection

Inch-Metric: Metric

Range: 25-50mm Digital step: 0.001 mm Max.Permissible Error
J MPE: 1 m Flatness: 0.3 m

Parallelism: 1 m

Data output: Digimatic S1

Display: LCD, character height 7.5 mm

Measuring face: Carbide-tipped, micro-lap finish

Measuring spindle: With spindle lock, 6.35 mm, spindle pitch 2 mm

Measuring force: 7 – 12N

Power supply: 1 battery CR2032

Battery life: Approx. 2 years (under normal use)
Approx. 4000 hours (continous use)

ON/OFF: Yes

ABS / INC (INC ZERO): Yes

Auto Power OFF after 20 min. non use: Yes

Low voltage alarm: Yes

Function lock: Yes

HOLD: Yes

PRESET: Yes

GO/NG judgement: Yes

Calculation function (with formula): Yes

Customizing keys: Yes

Calibration warning function: Yes

Mass: 325g
