Digital Indicator ID-U, ANSI/AGD Inch/Metric, 1, 0,0005/0,01mm 575-123
Product image
-50%
Product image
Product image

Digital Indicator ID-U, ANSI/AGD Inch/Metric, 1, 0,0005/0,01mm 575-123

Original price was: $136.50.Current price is: $68.25.

SKU: TEEl1wETdSD6m Category:

Description

An economical, slim-style Mitutoyo digital indicator with a long battery life suited to installation in measuring jigs. ABSOLUTE System scale for error free, high-speed measurement. SPC data output.

Specification

Digital/Analog: Digital

Inch-Metric: Inch/Metric

Delivered: In a box with SR44 battery and spindle lifting handle 137693

Range: 1″/25.4 mm

Digital step: 0.0005″/0.01 mm

Max. Permissible Error
E MPE (Total Range): 0.001″/0.02 mm

H MPE (Hysteresis): 0.001″/0.02 mm

R MPE (Repeatability): 0.0005″/0.01 mm

Measuring force MPL: 1.8 N

Protection: IP42

Type: ASME/ANSI/AGD Standard

Measuring force: 1,5 N

Mass: 140 g

Display: LCD, character height 8.5 mm

Max. response speed: Unlimited

Alarm: Low voltage, sensor error, ABS data composition error

Stem : 9.52 mm

Contact point: Carbide ball, thread: No.4-48UNF

Power supply: 1 battery SR44

Battery life: Approx. 20000 hours

Remarks: This digital indicator has data output but no integrated data button so for USB Input Tool Direct Cable (see optional accessory) the USB-ITPAK Software is required.

Digimatic data output: Yes

ON/OFF: Yes

ORIGIN (ABS-Zero): Yes

Counting direction switchable: Yes

Inch/Metric switchable: Yes

Digital Scale: Electrostatic capacitance type absolute linear encoder
