Dial Gauge, Lug Back, ANSI/AGD Type Jewelled Bearing, Shockproof, 0,025, 0,0001 2802A-10

Original price was: $93.10.Current price is: $46.55.

SKU: TEEUbjEj9iccm Category:

Description

This is a standard, inch dial indicator. It offers you the following benefits:

  • Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
  • No through screw holes on the frame and secure adhesion between the bezel and the crystal as well as the use of an O-ring prevents water or oil penetration.

Specification

Digital/Analog: Analog

Inch-Metric: Inch

Delivered: With certificate of inspection, bezel clamp

Range: 0,025

Range
per rev.:
0,01″

Graduation: 0.0001″

Accuracy: 0.0001″

H MPE (Hysteresis): 0,0001″

R MPE (Repeatability): 0,00003″

Error of indication one revolution: 0.0001″

MPE first one revolution: 0,0001″

MPE first 2 1/2 revolutions: 0,0001″

Type: ANSI/AGD Standard

Measuring force: 0,4-2 N

Mass: 164 g

Stem: 9.52 mm / 0.375″

Contact point: Carbide tipped, thread: 4-48UNF

Continuous dial: Yes

Shockproof: Yes
