Dial Gauge, Lug Back, ANSI/AGD Type 3803A-10 Grad .0001 Range .02 Reading 0-5-0

Original price was: $137.90.Current price is: $68.95.

SKU: TEEdOc0B7X4L5 Category:

Description

This is a standard, inch dial indicator. It offers you the following benefits:

  • Large-diameter dial face = 78 mm for easy reading
  • Supplied with limit markers and a bezel clamp as standard
  • 0,001″ / 0,0001″ graduation

Specification

Digital/Analog: Analog

Inch-Metric: Inch

Delivered: With certificate of inspection, bezel clamp

Range: 0,025

Range
per rev.:
0,01″

Graduation: 0.0001″

Accuracy: 0.0001″

H MPE (Hysteresis): 0,0001″

R MPE (Repeatability): 0,00003″

Error of indication one revolution: 0.0001″

MPE first one revolution: 0,0001″

MPE first 2 1/2 revolutions: 0,0001″

Type: ANSI/AGD Standard

Measuring force: 0,4-2 N

Mass: 245 g

Stem: 9.52 mm / 0.375″

Contact point: Carbide tipped, thread: 4-48UNF

Balanced dial: Yes

Continuous dial: Yes

Shockproof: Yes
