Dial Gauge, Flat Back, ISO Type 30mm, 0,01mm 2052AB

Original price was: $70.00.Current price is: $35.00.

SKU: TEEexfGldrVkQ Category:

Description

Standard Type, 30 mm Range, 0,01 mm Graduation

This is a standard dial indicator. It offers you the following benefits:

  • Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
  • No through screw holes on the frame and secure adhesion between the bezel and the crystal as well as the use of an O-ring prevents water or oil penetration.

Features

Digital/Analog: Analog

Inch-Metric: Metric

Type: EN ISO Standard

Delivered: With certificate of inspection

Range: 30 mm

Range
per rev.:
1 mm

Dial reading: 0-100

Graduation: 0.01 mm

MPE any 1/10
revolution:
7 m

MPE any 1/2
revolution:
11 m

MPE any 1
revolution:
12 m

MPE measuring range: 25 m

H MPE
(Hysteresis):
5 m

R MPE
(Repeatability):
3 m

Measuring force: 0,4-2,5 N

Mass: 152 g

Stem: 8 mm

Contact point: Carbide tipped, thread: M 2.5 x 0.45 mm

Continuous dial: Yes

Cushioned end point: Yes
