Dial Gauge, Flat Back, ANSI/AGD Type Jewelled Bearing, Shockproof, 0,05, 0,0001 2923AB-10

Original price was: $90.30.Current price is: $45.15.

SKU: TEEJnEYBHn5oc Category:

Description

Standard Type, Various Ranges, 0,0001″ Graduation – Inch

This is a standard, inch dial indicator. It offers you the following benefits:

  • Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
  • No through screw holes on the frame and secure adhesion between the bezel and the crystal as well as the use of an O-ring prevents water or oil penetration.

Specification

Digital/Analog: Analog

Inch-Metric: Inch

Functions: ANSI/AGD type

Delivered: With certificate of inspection, bezel clamp

Range: 0,05″

Range
per rev.:
0.01″

Graduation: 0,0001″

Accuracy: 0,0002″

H MPE (Hysteresis): 0,0001″

R MPE (Repeatability): 0,00003″

Measuring force: 0,4-2

Error of indication one revolution: 0,0002″

MPE first one revolution: 0,0001″

MPE first 2 1/2 revolutions: 0,0001″

MPE > 2 1/2-10 revolutions: 0,0002″

Type: ANSI/AGD Standard

Mass: 164 g

Stem: 9.52 mm / 0.375″

Contact point: Carbide tipped, thread: 4-48UNF

Balanced dial: Yes

Continuous dial: Yes

Reverse reading: Yes 3

Shockproof: Yes
