Dial Gauge, Flat Back, ANSI/AGD Type 3424AB-19

Original price was: $170.80.Current price is: $85.40.

SKU: TEEuLsw6xviMs Category:

Description

This is a standard, inch dial indicator. It offers you the following benefits:

  • Large-diameter dial face = 78 mm for easy reading
  • Supplied with limit markers and a bezel clamp as standard
  • 0,001″ / 0,0001″ graduation

Specification

Digital/Analog: Analog

Inch-Metric: Inch

Delivered: With certificate of inspection, bezel clamp

Range: 2

Range
per rev.:
0,1″

Graduation: 0.001″

Accuracy: 0.002″

H MPE (Hysteresis): 0,00033″

R MPE (Repeatability): 0,0002″

Error of indication one revolution: 0.002″

MPE first one revolution: 0,001″

MPE first 2 1/2 revolutions: 0,001″

MPE > 2 1/2-10 revolutions: 0,002″

Type: ANSI/AGD Standard

Measuring force: 0,4-3 N

Mass: 321 g

Stem: 9.52 mm / 0.375″

Contact point: Carbide tipped, thread: 4-48UNF

Continuous dial: Yes

Coaxial revolution counter: Yes

Shockproof: Yes
