Description
-
- A sturdy and robust dial gauge.
- Fitted with special brass bush bearings.
- Supplied with tolerance pointers.
- Strong and smooth metal bezel.
- Rigid, metal case.
- Aesthetically appealing protective top cap.
- Tungsten carbide ball anvil.
- Metric gauges conform to IS2092-1983 and for the European market to DIN878-1983.
- Inch gauges conform to ASME B89.1.10M-2001.
- Each gauge carries a calibration certificate giving actual values.
- Wide range of dial gauges in various ranges and readings available.
- Special dial gauges for OEMs also manufactured on request.
- Complete spares and after sales service available.
Baker (Mercer Style) Plunger indicator K08, Range 25mm, Graduation .01mm, Reading 0-100
Vendor Baker Part Number K08 Type Standard Indicators 57mm Series 2, Metric Graduation .01mm Unit of Measurement Metric Measuring Range 25mm Dial Face Size 57mm Measuring Force 2 N Dial Reading 0-100 Range Per Rev 1mm Back Centre Lug Back Repeatibility .005mm Hysteresis .003mm Dial Indicator Accuracy .015mm Repeatability .003mm Contact point Thread M2 x .45mm
