ABSOLUTE Digimatic Linear Gauge LGS-1012P, 12,7 mm, 0,01 mm, Counting positive 575-303
Product image
-50%
Product image
Product image

ABSOLUTE Digimatic Linear Gauge LGS-1012P, 12,7 mm, 0,01 mm, Counting positive 575-303

Original price was: $155.40.Current price is: $77.70.

SKU: TEEB2irAktePo Category:

Description

The LGS is a compact ABS linear gauge that offers you the following benefits:

  • Its ABSOLUTE Digimatic data output and IP-66 protection class give you best-of-breed technology.

Specification

Inch-Metric: Metric

Accuracy: 15 m

Measuring force: 2 N with spindle down, 1.8 N spindle horizontal, 1.6 N spindle upwards

Scale: Capacitance-type ABSOLUTE linear encoder

Stem : 8 mm

Max. response speed: 1600 mm/s;
(measuring by scanning not possible) mm/s

Contact point: 3 mm carbide Cable length: 2 m

Power supply: 5 to 10 V (5 mA max.)

Max. response speed: Unlimited (measuring by scanning cannot be performed)

Output signal: Digimatic output

Environmental conditions: 0 C to 40 C (20 % to 80 % rel. humidity, no condensation) C

Bearing type: Slide bearing

Direction of
counting: positive

Mass: 190 g (included cable)

Digital step: 0,01 mm
