2-Point Inside Measuring Instrument Bore Gauge, 10-18.5mm, Graduation 0,01mm 511-204-20

Original price was: $316.40.Current price is: $146.00.

SKU: TEESWP6uKPy7N Category:

Description

These are bore gauges that automatically self-centre via a centring bridge.
They offer you the following benefits:

  • A long plunger stroke gives you amazing accuracy.
  • Interchangeable washers 0.5 mm thick are supplied as standard accessories, so you can enable setting in small steps.
  • Contact points are carbide (>18 mm range), giving you high durability and wear resistance.
  • A large grip reduces heat transfer from the operator by 50%.

Specification

Inch-Metric: Metric

Digital/Analog: Analog

Range: 10-18.5mm Graduation: 0.01 mm

Stroke of contact point: 0.5 mm

Measuring depth: 100mm

No. Dial Indicator: 2046AB

Number of anvils: 9

Accuracy: 5 m

Repeatability: 2 m

Measuring force: 2 N

Delivered: In a box with bore gauge 511-209, dial indicator 2046AB, plastic cover for indicator 21DZA000, 9 anvils

Mass: 255 g
