Description
Features
DML3031
- Range: 0-12.7mm (0.5)
- Resolution: 0.01mm (0.0005)
- Accuracy: 0.02mm (0.001)
- Throat Depth: 30mm
- Zero setting at any point
- mm-inch conversion
- Data output
- Anvil Diameter: 10mm
- Power: 1.5V LR44 Battery
DML3033
- Range: 0-12.7mm (0.5)
- Resolution: 0.01mm (0.0005)
- Accuracy: 0.02mm (0.001)
- Throat Depth: 125mm
- Zero setting at any point
- mm-inch conversion
- Data output
- Anvil Diameter: 10mm
- Power: 1.5V LR44 Battery
DML3035
The DML3035 is designed specifically for taking measurements from sheet material or film. It has an extended reach of 300mm and a jaw capacity of 12.7mm. We are able to modify the DML3035 with various anvils to suit any application, please contact us for further information.
- Range: 0-12.7mm (0.5)
- Resolution: 0.01mm (0.0005)
- Accuracy: 0.03mm (0.0015)
- Throat Depth: 300mm
- Zero setting at any point
- mm-inch conversion
- Data output
- Power: 1.5V LR44 Battery
DML3036
The DML3036 is designed specifically for taking measurements from sheet material or film. It has an extended reach of 450mm and a jaw capacity of 12.7mm. We are able to modify the DML3036 with various anvils to suit any application, please contact us for further information.
- Range: 0-12.7mm (0.5)
- Resolution: 0.01mm (0.0005)
- Accuracy: 0.03mm (0.0015)
- Throat Depth: 450mm
- Zero setting at any point
- mm-inch conversion
- Data output
-
Power: 1.5V LR44 Battery
DML4031
- Range: 0-25mm (1)
- Resolution: 0.01mm (0.0005)
- Accuracy: 0.03mm (0.0015)
- Throat Depth: 30mm
- Zero setting at any point
- mm-inch conversion at any point
- USB Data output
- Power: 3V CR2032Battery (Included)
