02AZD880G U-WAVE-T, Buzzer Type Wireless Transmitter

U-WAVE-T, Buzzer Type

Wireless Transmitter

Item number: 02AZD880G

DescriptionThe Mitutoyo U-WAVE system enables easy wireless data communication from a measuring tool to a PC using the Digimatic protocol. Measurement workability is improved by eliminating the long and cumbersome data cables usually required and the user-friendly interface allows data to be loaded into any software product that accepts keyboard input, such as Excel* or Notepad.

Features

Wireless communication protocol: Proprietary (2,4 GHz by original specification based on IEEE 802.15.4)

Modulation method: DS-SS (Direct Sequence Spread Spectrum)

Measuring Instruments: Indicator, 3-Point Inside Micrometer,
Carbon Fibre Caliper, Height Gauge, a.s.o

Remarks: Standard

Data reception
indication: Buzzer and LED
(green, red, orange)

Communication distance: Approx. 20 m (within visible range)

Communication speed kbps: 250

Power supply: Battery CR2032

Communication with measuring tool: Digimatic (6 digits), Digimatic 2 (8 digits) automatic identification

Communication frequency: 2,4 GHz band (2,405-2,475 GHz, 15 channels, 5 MHz interval)

Transmission output: 2,5 mW (4 dBm) or below

OS compatibility: Windows 2000 Professional (SP4),
Windows XP Professional (SP2), Windows XP Home Edition (SP2), Windows Vista, Windows 7 (32bit, 64bit), Windows 8, 8. 1, 10 (32bit, 64bit), 11

Battery life: Approx. 400000 transmissions

Delivered: With 1 battery CR2032, screwdriver
