RHGP-H – High Gas Pressure Switch H Series – Auto Reset

Description

High gas pressure switch with adjustable setpoint and automatic reset mechanism to trip at rising pressure conditions and reset automatically when conditions return to setpoint

AvailablePressure Ranges:

• 1-7 PSI (0.07-0.48 bar) 803113401 RHGP-H 1-7
• 6-15 PSI (0.41-1.03 bar) 803113402 RHGP-H 6-15

Features and Specifications:

• Manufactured byCrossroads Controls, formerly by Antunes Controls
• Rugged Die-Cast Aluminum Housing.
• Approvals:UL, FM, CSA
• Electrical Ratings:
• 10A, 1/8HP @ 125 VAC.;
• 5A, 1/4 HP @ 250 VAC.;
• Pilot Duty, 125 VA @ 125-250 VAC.
• Max Surge Pressure:35PSI Max
• Max Ambient Temperature:140F / 60C
• Min. Ambient Temperature:-40F / -40C
• Connections:1/4″NPT Gas inlet, 1/8″NPT Gas vent

Accessories:

• Single Switch Mounting Bracket

Resources:

• Crossroads Controls Model H Gas Pressure Switch Datasheet
• Crossroads Controls Model H Gas Pressure SwitchInstallation Instructions
• Former Antunes Controls Literature:
• Model H Gas Pressure Switch Datasheet
• Model H Gas Pressure Switch Installation Instructions
