Composite Roughness Comparator Set

Description

• Surface Roughness Comparators are widely used in Drafting Rooms, Inspection Departments and Engineering Workshops. They provide a realistic idea of the feel, appearance and texture of machined components
• Sets are available with the individual plates marked in both MICROINCH ( AA) and the METRIC system (m Ra) Manufactured from Solid Electro Formed Nickel
• Conforms to ANSI-B-46-1978, ISO/R. 468 and US Military Standard 4566 accuracy within permitted tolerance of 12% as per ANSI, ISO and Mil Specs
• Invaluable for both visual and tactile inspection of component surface finish
• It consists of 30 specimens which cover a comprehensive range of both the inch system AA microinches and the metric system Ra micrometers
• The references plates are manufactured from electro formed solid nickel
• Flat Lapping: 2, 4 and 8 AA
• Reaming: 16, 32, 63 AA
• Grinding: 2, 4, 8, 16, 32, & 63 AA
• Horizontal Milling: 16, 32, 63, 125, 250, & 500 AA
• Vertical Milling: 16, 32, 63, 125, 250, & 500 AA
• Turning: 16, 32, 63, 125, 250, & 500 AA
