Mahr Millimess 1010 Dial Comparator – Range: 0.25mm ; Graduation 0.01mm

Description

• Large, high contrast dial face
• Adjustable tolerance markers
• Lockable fine adjustment screw
• Shockproof movement
• Mounting shank and measuring spindle are both made of hardened stainless steel
• Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
• Resistant to lateral forces (side play) acting on the measuring spindle
• Maximum sensitivity and accuracy are ensured by the jeweled movement in conjunction with the precision gears and pinions
• Box type protective housing
• Constant measuring force
• Measuring spindle can be retracted with either a screw in cable release or with a lifting knob

Measuring range mm 0.25 Product type 1010 Standard Factory standard Graduation value mm 0.01 Figur on dial face 25-0-25 Error limit Ge (m) 7m Error limit Gges (m) 8m Error limit Gt (m) 4m Measuring value hysteresis fu (m) 2m Repeatability fw (m) 2m Measuring force 1N Scale diameter 50mm Dial color White
