Ultrasonic Thickness Gauge TM210 PLUS

Description

Product Description

Ultrasonic thickness gauge TM210Plus

Feature

1. Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.

2. Transducer models are available for special application, including for coarse grain material and high temperature applications.

3. Probe-Zero function, Sound-Veloctiy-Calibration function.

4. Two-Point Calibration function.

5. Coupling status Indicator showing the coupling status.

6. Battery information indicates the rest capacity of the battery. Ultra-low power consumption, it is can continue working 100 hours.

7. Auto sleep and auto power off function to conserve battery life.

8. Usb port with Protective Membrane and datapro software to process the memory data on the PC.

9, Adjust gain function ,can easy to test the cast iron material,

Specifications

Display:12864 LCD with LED backlight. Measuring range:0.75mm~300.0mm (0.03inch~11.8 inch) Sound velocity:1000m/s~9999m/s (0.039~0.394in/s Display resolution:0.01mm or 0.1mm (lower than 100.0mm) 0.1mm (more than 99.99mm) Accuracy:(0.5%Thickness +0.02)mm, depends on Materials and conditions Units:Metric/Imperial unit seletable. Lower limit for steel pipes: 5MHz probe: F20mm3.0mm(F0.80.12 inch) 10MHz probe: F20mm3.0mm(F0.60.08 inch) Power Source:2pcs 1.5V AA size, batteries.100 hours typical operating time(LED backlight off). Communication:USB serial port Outline Dimensions:150mm74mm32mm Weight:238 g Four measurements readings per second for single point measurement, Memory for up to 5 files(up to 100 values for each file) of stored values
